Smoke Detector Indicators Standby: Green indicator flashes once per minute

Fault: Red indicator flashes once per minute

Alarm: Red indicator flashes once per second

Self-testing: Red indicator flashes once per second

Protection Area 30 m2–60 m2 Operating Principle Photoelectric Alarm Method Sound and LED Indicator Power 12V DC/PoE and 3V lithium battery Operating Current ≤ 30uA (Camera excluded)

≤ 300mA (Camera included)

Back-up Battery Life ＞ 3 years Alarm Classification Smoke alarm, fault alarm, low battery alarm Alarm Sound Pressure ≥ 80 dB (A) @ 3 m (9.84 ft) Network Camera Appearance Circular Image Sensor 1/2.7″ CMOS Max. Resolution 2592 (H) × 1944 (V) Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3s~1/100000s Minimum Illumination 0.007Lux (color)

0.003Lux (dark)

0Lux (IR)

S/N Ratio ＞ 56 dB Illumination Distance Distance up to 20 m (65.62 ft) Illuminator Number 2 (IR LED) Lens Lens Type Fixed-focal Mount Type M8 Focal Length 2.0 mm Aperture F2.0 Field of View Horizontal: 144°; Vertical: 92°; Diagonal: 179.6° Iris Control Fixed Close Focus Distance 0.2 m (0.66 ft) Artificial Intelligence AI Event Flame detection Video Image Setting Brightness; contrast; sharpness; saturation; gamma OSD Channel/time/place/voltage of back-up battery Video Manual record; external alarm; alarm video record; timing record Micro SD Card Max. 256 GB Compression H.265; H.264; H.264H; H.264B Smart Codec Smart H.265+/ Smart H.264+ Frame Rate Main stream:

2592×1944 (1 fps-20 fps)

2688×1520 (1 fps–25/30 fps)

2560×1440 (1 fps–25/30 fps)

2304×1296 (1 fps–25/30 fps)

1920×1080 (1 fps–25/30 fps)

Sub stream:

D1 (1 fps–20 fps)

D1 (1 fps–25/30 fps)

Third stream:

1920×1080 (1 fps-17/24 fps)

Video Bit Rate H.264: 32 Kbps–10240 Kbps

H.265: 12 Kbps–7168 Kbps

Day/Night Auto (ICR) BLC Yes HLC Yes WDR 90 dB White Balance Auto/natural/street lamp/outdoor/manual/regional custom Gain Control Auto; manual Noise Reduction 3D NR Default Frame Rate under Default Resolution 2048 Kbps (2688 × 1520) Defog Yes Image rotation, mirroring, flipping Yes Privacy Masking 8 areas Language English; TradChinese; Italian; Spanish; Japanese; Russian; French; German; Portuguese; Turkish; Polish; Romanian; Hungarian; Korean; Czech; Dutch; Ukrainian;Vietnamese; Arabic; SpanishEU; Hebrew; Thai; Bahasa Indonesia Audio Audio Interface Yes Built-in MIC Yes Built-in Speaker Yes Audio Compression PCM; G.711a; G.711Mu; G.726; AAC; G.723 Audio Sampling Frequency 8KHz/16KHz/32KHz/48KHz/64KHz Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; scene changing; smart motion detection; audio detection; flame detection; smoke detected alarm; fault alarm; smoke alarm disconnected; low battery alarm Network Communication 1 RJ-45 PoE 10M/100M Ethernet ports Protocol HTTP;TCP;RTSP;RTP;UDP;RTCP;SMTP;FTP;DHCP;DNS;DDNS;IPv4/v6;SNMP;QoS;UPnP;NTP Interoperability ONVIF; MileStone; Genetec; CGI; PISA User 10 channels at most Storage FTP; SFTP; Micro SD card (256G); NAS Browser IE7 and newer versions; Chrome 8+; Firefox 3.5+; Safari 5+ Security Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1X; controlled network access Certification Certification CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

FCC: 47 CFR FCC Part 15, Subpart B

Port Audio Input 1 channel (RCA port) Audio Output 1 channel (RCA port) Alarm Input Interface 2 channels In: 5mA 5V DC Alarm Output Interface 2 channels Out: 300mA 12V DC RS 485 Port 1 channel Electrical Operating Power Adapter: 12V DC(±25%); PoE: 802.3af Power Supply DC12V+PoE Power Consumption Basic power consumption: 2.1W (12V DC); 2W (PoE)

Max. power consumption (ICR + IR LED intensity): 4.9W (12V DC); 4.8W (PoE)

Environmental Operating Temperature –10°C to +55°C (+14°F to +131°F) Operating Humidity 0%–95% RH (non-condensing) Construction Casing Plastic Product Dimensions Φ120 mm × 79 mm (Φ4.72″ × 3.11″ ) Package Dimensions 164 mm × 153 mm × 111 mm (6.46″ × 6.02″ × 4.37″)(L × W × H) Net Weight 442 g ( 0.98 lb) Gross Weight 613 g ( 1.35 lb) Installation Ceiling mount Power Adapter Excluded Lens Included Smoke Detector Indicators Standby: Green indicator flashes once per minute
