Thermal Detector Type Vanadium oxide uncooled focal plane detector Effective Pixels 120 (H) × 90 (V) Pixel Pitch 17 μm Spectral Range 8 μm–14 μm Sensitivity (NETD) < 60mK@f/1.0 Focal Length 1.2 mm Field of View Horizontal: 90°
Vertical: 67.5° Thermal Focus Control Fixed-focal Field of Depth > 3 cm Aperture F1.1 Flame Detection Distance 10 m: 10 cm × 10 cm Visible Image Sensor 1/2.7″ CMOS Max. Resolution 1920 (H) × 1080 (V) Pixel 2 MP Min. Illumination Color: 0.05 lux
B/W: 0.005 lux
0 lux (IR on) Visible AGC Auto; Manual Visible Noise Reduction 2D NR; 3D NR S/N Ratio ≥ 55 dB Electronic Shutter Speed 1 s–1/30,000 s (manual/auto) BLC Yes WDR DWDR HLC Yes Day/Night Auto (ICR); Color and B/W Iris Control Fixed Image Flip 90°; 180°; 270° Exposure Compensation Yes Visible Focus Control Fixed-focal Focal Length 4 mm Field of View H: 86°
V: 46°
D: 101° Close Focus Distance 1 m (3.28 ft) Aperture F1.6 Illuminator IR Illuminator On/Off Control Auto; Manual Illumination Distance 15 m (49.21 ft) Illuminator Angle 100° Audio and Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG Resolution Visible:
Main stream: 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576); 1920×1080 by default
Sub stream: 720p (1280 × 720); D1 (704 × 576); CIF (352 × 288); 352 × 288 by default Video Frame Rate Visible:
Main stream: 1 fps–25 fps adjustable, 25 fps by default Sub stream: 1 fps–25 fps adjustable, 15 fps by default
Audio Compression G.711a; G.711mu; AAC; PCM Image Encoding Format JPEG Function Two-way Audio Yes Visible and Audible Alarm Yes Network Protocol HTTPS; HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP Interoperability ONVIF; GB/T28181; CGI; Dahua SDK Browser IE: IE 9 and later (Edge is not supported)
Chrome: 42 and earlier
Firefox: 42 and earlier User/Host Up to 10 (total bandwidth: 100 MB) Security Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access User Management Up to 10 users; supports multi-level user permissions (2 levels): management group and user group Malfunction Detection Network disconnection detection; IP conflict detection Intelligence Flame Detection Yes Cold/Hot Spot Trace Yes Port Network Port 1 × RJ-45 (10/100 Base-T) Alarm Input 1 channel Alarm Output 1 channel Alarm Linkage Relay output/Email/Snapshot Alarm Event Local audible and visual alarm notification Power Power Supply 12 VDC ± 20%; PoE Power Consumption Basic: 4.5 W (12 VDC, LED off)
Max.: 10.1 W (12 VDC, LED on, heat on) Environment Operating Temperature –20°C to +60°C (–4°F to +140°F) Operating Humidity ≤ 95% Storage Temperature –20°C to +70°C (–4°F to +158°F) Construction Protection IP66, anti-surge 2 kV; anti-elctrostatic 6 kV (touched by objects); anti-elctrostatic 8 kV (air) Product Dimensions φ110mm × 88.6mm (φ4.33″ × 3.49″) Net Weight ≤ 0.85 kg (1.87 lb) Gross Weight ≤ 1 kg (2.20 lb) Installation Ceiling mount Power Optional Lens Included Bracket Junction mount: PFA130-E Thermal Detector Type Vanadium oxide uncooled focal plane detector Effective Pixels 120 (H) × 90 (V) Pixel Pitch 17 μm Spectral Range 8 μm–14 μm Sensitivity (NETD) < 60mK@f/1.0 Focal Length 1.2 mm Field of View Horizontal: 90°
